Surface Tension - Practice Questions & MCQ

Edited By admin | Updated on Sep 18, 2023 18:34 AM | #JEE Main

Quick Facts

  • 26 Questions around this concept.

Solve by difficulty

A thin liquid film formed between a U- shaped wire and a light slider supports a weight of 1.5 \times10-2 N ( see figure) The length of the slider is 30 cm and its weight is negligible. The surface tension of the liquid film is:

The fundamental unit which has the same power in the dimensional formula of surface tension and viscosity is


As shown in the figure, the tension in the horizontal cord is 30 N. The weight 'W' and the tension in the string PA in 'N' respectively are;-



For a surface molecule

a) the net force on it is zero

b) there is a net downward force

c) the potential energy is less than that of a molecule inside

d) the potential energy is more than that of a molecule inside

Given below are two statements:
Statement I: The hot water flows faster than cold water.
Statement II: Soap water has higher surface tension as compared to fresh water.

In light of the above statements, choose the correct answer from the options given below

Concepts Covered - 1

Surface tension

Surface tension is the elastic tendency of a fluid surface which makes it acquire the least surface area.

If we draw an imaginary line on the free surface of the liquid as shown in the below figure.

Then Surface tension of a liquid is measured by the force acting per unit

length on either side of an imaginary line.

So  Surface tension of a liquid  is given by

$$
T=\frac{F}{l}
$$


Where

$$
F \rightarrow \text { force }
$$

$l \rightarrow$ imaginary length
The direction of this force is perpendicular to the line and tangential to the free surface of the liquid.
- It depends only on the nature of liquid and is independent of the area of surface or length of the imaginary line considered.
- It is a scalar quantity.
- Unit of Surface Tension-

$$
\begin{aligned}
& \frac{N}{m}-i n \text { S.I. Unit } \\
& \frac{d y n e}{c m}-i n \text { c.g.s. Unit }
\end{aligned}
$$

- Dimension- $M T^{-2}$

  • Example-

     Raindrops are spherical in shape because each drop tends to acquire minimum surface area due to surface tension, and for a  given volume, the surface area of the sphere is minimum.

  • The surface tension of liquid decreases with the rise of temperature.
