Spring Force is considered one of the most asked concept.
31 Questions around this concept.
A spring is compressed by a distance x. If the same spring is compressed by a distance of 2x, the force required to compress it by 2x will be:
What is the relationship between =spring constant and
=length of spring?
Assertion: The force exerted by a spring is directly proportional to its displacement from its equilibrium position.
Reason: The spring force follows Hooke's Law, which states that the force exerted by a spring is directly proportional to its displacement from its equilibrium position.
JEE Main 2025: Session 2 Result Out; Direct Link
JEE Main 2025: College Predictor | Marks vs Percentile vs Rank
New: JEE Seat Matrix- IITs, NITs, IIITs and GFTI | NITs Cutoff
Latest: Meet B.Tech expert in your city to shortlist colleges
For a Series combination of springs, the effective spring constant is given by?
For the parallel combination of springs having spring constant , the effective spring constant is given by?
A block with a mass of 6 kg is suspended from an ideal spring having negligible mass and stretches the spring by 0.3m. Then find the force constant of spring in N/m:
Which of the following graphs shows the spring constant $'k'$ versus length ' $l^{\prime}$ of the spring correctly?
Ranked #42 among Engineering colleges in India by NIRF | Highest Package 1.3 CR , 100% Placements | Last Date to Apply: 28th April
Merit Scholarships | NAAC A+ Accredited | Top Recruiters : E&Y, CYENT, Nvidia, CISCO, Genpact, Amazon & many more
Spring force is given by:
$
F_{s p}=-k \Delta x
$
where,
$\mathrm{F}_{\mathrm{sp}}=$ spring force
$\mathrm{k}=$ spring constant
$\Delta x=$ net elongation or compression in the spring
2. Force at every point in a massless spring remains same, so we can solve questions of spring by considering it as string and spring force as tension.
3. Spring constant:- $k \alpha \frac{1}{l}$
Where, k=spring constant
l=length of spring
4. Combination of Spring:-
Series combination:-
$\frac{1}{k_{e q}}=\frac{1}{k_1}+\frac{1}{k_2}$
Parallel combination:-
$k_{e q}=k_1+k_2$
