Lens Maker's formula is considered one the most difficult concept.
65 Questions around this concept.
What is the position and nature of the image formed by the lens combination shown in the figure? (f1, f2 are focal lengths )
The focal length of the lens as shown in the figure is:
The radius of curvature for the convex lens is 20Cm for each surface Its refractive index is 1.5 then the focal length is
JEE Main Session 2 Memory Based Questions: April 2- Shift 1 | Shift-2 | Overall Analysis
JEE Main 2025: Mock Tests | PYQs | Rank Predictor | College Predictor | Admit Card Link
New: Meet Careers360 experts in your city | Official Question Papee-Session 1
Apply to TOP B.Tech /BE Entrance exams: VITEEE | MET | AEEE | BITSAT
The refractive index of the material of a concave lens is $\mu$. It is immersed in a medium of refractive index $\mu_{1.}$ A parallel beam of light is incident on the lens. The path of the emergent rays when $\mu_1>\mu$ is :
The following graph depicts the inverse of magnification versus the distance between the object and lens data for a setup. The focal length of the lens used in the setup is
Lens Maker's formula -
Derivation of Lens maker formula -
Let us take a lens having refractive index = $\mu_2$ and the surrounding is having refractive index = $\mu_1$. Also, let us assume that the lens is having two refracting surfaces having radii R1 and R2.
Here I' is the intermediate image and I is the final image.
As we have learned the formula of refraction at a single spherical surface. Let us apply this to the surface ACB, we get -
$
\frac{\mu_2}{v_1}-\frac{\mu_1}{u}=\frac{\mu_2-\mu_1}{R_1} \ldots \text { (1) }
$
Similarly for the second surface ADB-
$
\frac{\mu_1}{v}-\frac{\mu_2}{v_1}=\frac{\mu_1-\mu_2}{R_2} \ldots \text { (2) }
$
Here, $\mathrm{v}_1$ is the position of the image formed by the first surface and the same image will now act as an object for the second surface.
Now adding equations (1) and (2),
$
\begin{aligned}
& \frac{\mu_1}{v}-\frac{\mu_1}{u}=\left(\mu_2-\mu_1\right)\left[\frac{1}{R_1}-\frac{1}{R_2}\right] \\
& \Rightarrow \frac{1}{v}-\frac{1}{u}=\left(\frac{\mu_2}{\mu_1}-1\right)\left[\frac{1}{R_1}-\frac{1}{R_2}\right]
\end{aligned}
$
Now we are going to arrange this equation in the desired as -
$
\text { So, put, } u=\infty \text { and } v=f
$
we get,
$
\begin{aligned}
& \frac{1}{f}=\left(\frac{\mu_2}{\mu_1}-1\right)\left[\frac{1}{R_1}-\frac{1}{R_2}\right] \\
& \frac{\mathbf{1}}{\mathbf{f}}=\left(\mu_{\text {relative }}-1\right)\left(\frac{1}{\mathbf{R}_{\mathbf{1}}}-\frac{1}{\mathbf{R}_{\mathbf{2}}}\right)
\end{aligned}
$
Where,
$
\mu_{\text {relative }}=\frac{\mu_{\text {lens }}}{\mu_{\text {medium }}}
$
