    Magnetic Field Due To Current In Straight Wire - Practice Questions & MCQ

    Edited By admin | Updated on Sep 18, 2023 18:34 AM | #JEE Main

    Quick Facts

    • Magnetic Field due to current in straight wire is considered one of the most asked concept.

    • 83 Questions around this concept.

    Solve by difficulty

     The magnetic field at the origin due to the current flowing in the  wire as shown in figure below is



    Two identical conducting wires $A O B$ and $C O D$ are placed at right angles to each other. The wire $A O B$ carries an electric current $I_1$ and $C O D$ carries a current $I_2$. The magnetic field on a point lying at a distance $d$ from $O$, in a direction perpendicular to the plane of the wires $A O B$ and $C O D$, will be given by

    In given fig. Magnetic Induction at the centre of the arc due to the current in portion AB will be











    JEE Main 2026: January Question Paper with Solutions

    JEE Main 2026 Tools: College Predictor

    JEE Main 2026: Important Formulas | Foreign Universities in India

    Comprehensive Guide: IIT's | NIT'sIIIT's

    The current is flowing in south direction along a power line. The direction of magnetic field above the power line (neglecting earth's field) is

    The magnetic field at a distance r from a long wire carrying current i is 2 T. The magnetic field at a distance of 2r is.

    The value of the magnetic field at any point will be zero if -

    Two straight long conductors AOB and COD are perpendicular to each other and carry currents i1 and i2. The magnitude of the magnetic induction at a point P at a distance a from the point O in a direction perpendicular to the plane ACBD is

    Amity University-Noida B.Tech Admissions 2026

    Among top 100 Universities Globally in the Times Higher Education (THE) Interdisciplinary Science Rankings 2026

    UPES B.Tech Admissions 2026

    Last Date to Apply: 26th March | Ranked #43 among Engineering colleges in India by NIRF | Highest Package 1.3 CR , 100% Placements

    Choose the correct sketch of the magnetic field lines of a circular loop shown by the dot \bigodot and \bigotimes

    One end of an infinitely long thin straight conductor makes an angle $30^{\circ}$ with a point. The perpendicular distance from the conductor is d. Magnitude of magnetic field at the point is (The current through the conductor is I)

    JEE Main 2026 College Predictor
    Discover your college admission chances with the JEE Main 2026 College Predictor. Explore NITs, IIITs, CFTIs and other institutes based on your percentile, rank, and details.
    Try Now

    Concepts Covered - 1

    Magnetic Field due to current in straight wire

    Magnetic Field due to current in a straight wire:

    Magnetic field lines around a current-carrying straight wire are concentric circles whose centre lies on the wire.



    The magnitude of magnetic field B, produced by a straight current-carrying wire at a given point is directly proportional to the current I pairing through the wire i.e. B is inversely proportional to the distance 'r' from the wire $\left(B \propto \frac{1}{r}\right)$  as shown in the figure given below.





    Derivation:

    The directions of magnetic fields due to all current elements are the same in the figure shown, we can integrate the expression of magnitude as given by Biot-Savart law for the small current element  dy as shown in the figure





    $
    B=\int \mathrm{dB}=\frac{\mu_0}{4 \pi} \int \frac{I d y \sin \theta}{x^2}
    $


    In order to evaluate this integral in terms of angle $\phi$, we determine $d y, \mathrm{x}$ and $\theta$ in terms of perpendicular distance " r " (which is a constant for a given point) and angle " $\phi$ ". Here,

    $
    \begin{aligned}
    y & =r \tan \phi \\
    d y & =r \sec ^2 \phi d \phi \\
    x & =r \sec \phi \\
    \theta & =\frac{\pi}{2}-\phi
    \end{aligned}
    $


    Substituting in the integral, we have :

    $
    \Rightarrow B=\frac{\mu_0}{4 \pi} \int \frac{I r \sec ^2 \phi d \phi \sin \left(\frac{\pi}{2}-\phi\right)}{r^2 \sec ^2 \phi}=\frac{\mu_0}{4 \pi} \int \frac{I \cos \phi d \phi}{r}
    $


    Taking out I and r out of the integral as they are constant:

    $
    \Rightarrow B=\frac{\mu_0 I}{4 \pi r} \int \cos \phi d \phi
    $


    Integrating between angle $-\phi_1$ and $\phi_2$, we have

    $
    \begin{gathered}
    \Rightarrow B=\frac{\mu_0 I}{4 \pi r} \int_{-\phi_1}^{\phi_2} I \cos \phi d \phi \\
    \Rightarrow B=\frac{\mu_0 I}{4 \pi r}\left(\sin \phi_2-\sin \left(-\phi_1\right)\right)
    \end{gathered}
    $


    Note: $-\phi_1$ is taken because it is measured in the opposite sense of $\phi_2$ with respect to the reference line ( negative x -axis here)

    $
    \Rightarrow B=\frac{\mu_0 I}{4 \pi r}\left(\sin \phi_2+\sin \phi_1\right)
    $


    Magnetic field due to a current-carrying wire at a point P which lies at a perpendicular distance r from the wire, as shown, is given as:

                                                           $B=\frac{\mu_0}{4 \pi} \frac{i}{r}\left(\sin \phi_1+\sin \phi_2\right)$

    From figure, $\alpha=\left(90^{\circ}-\phi_1\right)$ and $\beta=\left(90^{\circ}+\phi_2\right)$
    Hence, it can be also written as $B=\frac{\mu_o}{4 \pi} \frac{i}{r}(\cos \alpha-\cos \beta)$



    Different cases:

    Case 1: When the linear conductor XY is of finite length and the point P lies on it's perpendicular bisector as shown



    $B=\frac{\mu_0}{4 \pi} \cdot \frac{i}{r}(2 \sin \phi)$

    Case 2: When the linear conductor XY is of infinite length and the point P lies near the centre of the conductor

    $B=\frac{\mu_0}{4 \pi} \frac{i}{r}\left[\sin 90^{\circ}+\sin 90^{\circ}\right]=\frac{\mu_0}{4 \pi} \frac{2 i}{r}$

    Case 3: When the linear conductor is of semi-infinite length and the point P lies near the end Y or X

    $B=\frac{\mu_0}{4 \pi} \frac{i}{r}\left[\sin 90^{\circ}+\sin 0^{\circ}\right]=\frac{\mu_0}{4 \pi} \frac{i}{r}$

    Case 4: When point P lies on the axial position of the current-carrying conductor then magnetic field at P,

    $B=\frac{\mu_o}{4 \pi} \frac{i}{r}(\cos \alpha-\cos \beta)=\frac{\mu_o}{4 \pi} \frac{i}{r}(\cos 0-\cos 0)=0$

    Note:

    • The value of magnetic field induction at a point, on the centre of separation of two linear parallel conductors carrying equal currents in the same direction, is zero.
    • If the direction of the current in the straight wire the known then the direction of the magnetic field produced by a straight wire carrying current is obtained by Maxwell's right-hand thumb rule.



    Study it with Videos

    Magnetic Field due to current in straight wire
