Horizontal and Vertical Ellipse - Practice Questions & MCQ

Edited By admin | Updated on Sep 18, 2023 18:34 AM | #JEE Main

Syllabus

Quick Facts

Horizontal and Vertical Ellipse is considered one the most difficult concept.
49 Questions around this concept.

Solve by difficulty

EASY

Consider an ellipse, whose centre is at the origin and its major axis is along the $x$-axis. If its eccentricity is $\frac{3}{5}$ and the distance between its foci is 6 , then the area (in sq. units) of the quadrilateral inscribed in the ellipse, with the vertices as the end points of major and minor axes of ellipse, is

View Solution

The equation of the ellipse whose axes are the axes of coordinates and which passes through the point (–3, 1) and has eccentricity $\sqrt{\frac{2}{5}}$ is

$3x^{2}+5y^{2}-15=0\;$

$\; 5x^{2}+3y^{2}-32=0\;$

$\; 3x^{2}+5y^{2}-32=0\; \;$

$\; 5x^{2}+3y^{2}-54=0$

View Solution

Concepts Covered - 1

Horizontal and Vertical Ellipse

Horizontal and Vertical Ellipse

When the major axis is along Y -axis and the minor axis is along X -axis, i.e. b > a
Then, $\mathrm{AA}^{\prime}=2 \mathrm{a}$ and $\mathrm{BB}^{\prime}=2 \mathrm{~b}$
The foci are $\mathrm{S}(0$, be $)$ and $S^{\prime}(0$, be $)$

The equation of directrix MZ and M’Z’ are $y=\frac{b}{e} \quad$ and $y=-\frac{b}{e}$

Equation	$\frac{x^{2}}{a^{2}}+\frac{y^{2}}{b^{2}}=1 ; a>b$	$\frac{x^{2}}{a^{2}}+\frac{y^{2}}{b^{2}}=1 ; a<b$
Graph
Centre	(0 ,0)	(0, 0)
Vertices	$(\pm \mathrm{a}, 0)$	$(0, \pm \mathrm{b})$
Length of Major Axis	2a	2b
Length of Minor Axis	2b	2a
Foci	$(\pm \mathrm{ae}, 0)$	$(0, \pm \mathrm{be})$
Distance b/w foci	2ae	2be
Equation of Directrices	$\mathrm{x}=\pm \frac{\mathrm{a}}{\mathrm{e}}$	$y=\pm\frac{b}{e}$
Distance b/w Directrices	$\frac{2 \mathrm{a}}{\mathrm{e}}$	$\frac{2 \mathrm{b}}{\mathrm{e}}$
Eccentricity, e	$\mathrm{e}=\sqrt{1-\frac{\mathrm{b}^{2}}{\mathrm{a}^{2}}}$	$\mathrm{e}=\sqrt{1-\frac{\mathrm{a}^{2}}{\mathrm{b}^{2}}}$
Length of Latusrectum	$\frac{2 \mathrm{b}^{2}}{\mathrm{a}}$	$\frac{2 \mathrm{a}^{2}}{\mathrm{b}}$
Endpoint of Latusrectum	$\left(\pm \mathrm{ae}, \pm \frac{\mathrm{b}^{2}}{\mathrm{a}}\right)$	$\left(\pm \frac{\mathrm{a}^{2}}{\mathrm{b}}, \pm \mathrm{be}\right)$
Focal radii	SP+S'P = 2a	SP+S'P = 2b
Parametric coordinates	${\color{Blue} (a \cos \theta, b \sin \theta) \quad 0 \leq \theta \leq 2 \pi }$	${\color{Blue} (a \cos \theta, b \sin \theta) \quad 0 \leq \theta \leq 2 \pi }$
Tangent at vertices	$\mathrm{x}=\pm \mathrm{a}$	$y=\pm b$
