Position of centre of mass for solid cone is considered one of the most asked concept.
3 Questions around this concept.
Distance of the centre of mass of a solid uniform cone from its vertex is z0. If the radius of its base is R and its height is h then z0 is equal to :
Have a look at the figure of a solid cone
Since it is symmetrical about $y$-axis
So we can say that its $x_{c m}=0$ and $z_{c m}=0$
Now we will calculate its $Y \mathrm{~cm}$ which is given by
$
y_{\mathrm{cm}}=\frac{\int y \cdot d m}{\int d m}
$
So Take a small elemental disc of mass $d m$ of radius $r$ at a vertical distance $y$ from the bottom as shown in the figure.
So $\quad d m=\rho d v=\rho\left(\pi r^2\right) d y$
Here
$
\rho=\frac{M}{V}=\frac{M}{\frac{1}{3} \pi R^2 H}
$
And from similar triangle
$
\begin{aligned}
\frac{r}{R} & =\frac{H-y}{H} \\
r & =\left(\frac{H-y}{H}\right) R \\
y_{c m} & =\frac{\int y \cdot d m}{\int d m} \\
y_{c m} & =\frac{1}{M} \int_0^H y \cdot d m=\frac{1}{M} \int_0^H y \frac{3 M}{\pi R^2 H}\left(\pi r^2\right) d y=\frac{H}{4} \\
\text { So, }^{\quad} \mathbf{y}_{\mathrm{cm}} & =\frac{\mathbf{H}}{\mathbf{4}} \text { from bottom O }
\end{aligned}
$
Or, Centre of Mass of a solid cone will lie at distance $\frac{3 h}{4}$ from the tip of the cone.
