Sine wave travelling on string is considered one the most difficult concept.
25 Questions around this concept.
A simple harmonic progressive wave is represented by the equation, , where
are in cm and
is in second. At any instant the phase difference between two particles separated by 2 cm in
- direction is?
A travelling wave is described by the equation
The velocity of the wave is : [all the quantities are in SI unit]
A sine wave is travelling through a string. The relation between particle velocity $\left(V_p\right)$ and wave velocity $(V)$ is given by
New: JEE Main 2025 Session 1 Result OUT; Check Now | Rank Predictor
JEE Main 2025: College Predictor | Marks vs Rank vs Percentile | Top NITs Cutoff
JEE Main 2025: January Session Official Question Paper for All Shifts | Exam Analysis
JEE Main 2025: High Scoring Topics | Sample Papers | Mock Tests | PYQs
The equation of a progressive wave travelling on a string is $y=4 \sin \frac{\pi}{2}\left(8 t-\frac{\pi x}{8}\right) \mathrm{cm}$. The velocity of the wave is
If V is the velocity of the wave and $\omega$ is the angular velocity, then the propagation constant ( K ) of the wave is given by
The sine wave or sinusoid is a mathematical function that describes a smooth repetitive oscillation.
$
y(t)=A \sin (\omega t+\phi)
$
Here $\omega$, is the angular frequency i.e,
$\omega=\frac{2 \pi}{T}=2 \pi f {\text { It defines how many cycles of the oscillations are there. }}$
and $\phi=$ phase angle
General form :
a spatial variable $x$ that represents the position on the dimension on which the wave propagates, and a characteristic parameter $k$ called wave number which represents the proportionality between the angular frequency $\omega$ and the linear speed (speed of propagation ) $v$.
which is $y(x, t)=A \sin (k x-\omega t+\phi)$ when the wave is moving towards the right $y(x, t)=A \sin (k x+\omega t+\phi)$ when the wave is moving towards the left.
The wavenumber is related to the angular frequency by:
$
k=\frac{\omega}{v}=\frac{2 \pi f}{v}=\frac{2 \pi}{\lambda}
$
Also,
Particle velocity $=-($ wave velocity $) \times($ slope of $y$ vs $x$ graph $)$
$
\begin{aligned}
& \Longrightarrow V_p=-v\left(\frac{\partial y}{\partial x}\right) \\
& \Longrightarrow \frac{\partial y}{\partial t}=-v\left(\frac{\partial y}{\partial x}\right)
\end{aligned}
$
