P-N Junction As A Rectifier - Practice Questions & MCQ

Edited By admin | Updated on Sep 18, 2023 18:34 AM | #JEE Main

Quick Facts

  • 6 Questions around this concept.

Solve by difficulty

A half-wave rectifier has an input voltage of 220 \mathrm{~V}_\mathrm{rms}. If the step-down transformer has a turns ratio of 4: 1, what is the peak load voltage? Ignore the diode drop.

A full wave p – n diode rectifier uses a load resistor of \mathrm{1500\Omega } No filter is used. The forward bias resistance of the diode is \mathrm{10\Omega } The efficiency of the rectifier is:

For given electric voltage signal dc value is



Concepts Covered - 1

P-N Junction as a rectifier (I)

Application of junction diode as a rectifier-

A rectifier converts Alternating Current into Direct Current. Sometimes we have an AC power point but need to connect a device that requires a DC.

The Volt-Ampere characteristics of a junction diode give a reason for how current is passed through the diode only when it is forward biased. So, when an alternating voltage is applied across a junction diode, then the current will flow only in the part where it is forward biased. Due to this property junction diode is used to rectify alternating voltage/ current. The circuit used for this purpose is a Rectifier.

Based on the usage a junction diode can be used as a rectifier in two ways:

Half-wave Rectifier-





Look at the diagram given above. An alternating voltage is applied across a junction diode which is connected to a load in a series connection. In this case, only during those half cycles of the AC input when the diode is forward biased, a voltage will appear across the load. This type of circuit, which rectifies only one half of the input current is a Half-wave Rectifier.

The alternating current is supplied at points A and B. During the alternating cycle, when the voltage at point A is positive, the diode is forward biased. This will happen when the diode conducts. On the other hand, the diode is reverse biased when the voltage at point A is negative, and it doesn’t conduct. Generally, for all practical purposes, the reverse saturation current can be considered zero since it is negligible.

Hence, we will get output voltage only through one half of the input cycle. Also, there will be no current available in the other half. Hence, the output still varies between positive to zero but the negative cycle is cut off and the output voltage is said to be rectified.
